MRCOOL® 30K Hyper Heat Central Ducted Heat Pump Condenser –

Upgrade your home comfort with the MRCOOL® 30K Hyper Heat Central Ducted Heat Pump Condenser (2nd Gen) — a high-performance outdoor unit designed to deliver dependable heating and cooling in both extreme winter and summer conditions.

Built with a DC inverter compressor and advanced variable-speed technology, this condenser provides strong performance while maximizing efficiency. With ratings up to 16.8 SEER2, 11.7 EER2, and 10 HSPF2-4, it helps reduce energy costs while maintaining consistent indoor comfort. It also delivers enhanced heating performance, producing up to 34,000 BTU of heating capacity.

This unit supports WiFi and app control and is designed to pair with compatible MRCOOL central ducted air handlers, including MRCOOL® VersaPro® central ducted air handler models. Optional accessories such as an auxiliary heat kit (sold separately) can be added depending on the air handler configuration.

The system uses R-454B refrigerant, a modern refrigerant designed to reduce environmental impact compared to older refrigerants. For long-term durability, the outdoor cabinet is constructed from painted galvanized steel, built to withstand harsh weather and outdoor hazards.

For peace of mind, MRCOOL backs this condenser with a 10-year warranty covering the compressor, parts, and labor, with labor coverage automatically activated upon installation — no registration required.

• 30,000 BTU Hyper Heat central ducted condenser (2.5 Ton)

• Enhanced heating output: up to 34,000 BTU heating

• DC inverter compressor + variable-speed technology

• High efficiency: up to 16.8 SEER2 / 11.7 EER2

• Strong heating performance: HSPF2-4 up to 10

• 208/230V single-phase power

• Uses R-454B refrigerant

• WiFi + app compatible

• ETL Certified + Energy Star Certified + AHRI Certified

• Durable painted galvanized steel cabinet

• 10-year compressor, parts & labor warranty

System Type: Central Ducted Split System Heat Pump (Outdoor Condenser)
Series: MRCOOL Central Ducted Hyper Heat (2nd Gen)
Model: CENTRAL-30-HP-C-230B00-O
Tonnage: 2.5 Ton

Capacity:
Cooling Capacity: 30,000 BTU
Heating Capacity: 34,000 BTU

Efficiency Ratings:
SEER2: 16.8
EER2: 11.7
HSPF2-4: 10
HSPF2-5: 8.3

Airflow:
CFM: 3001.8

Electrical:
Voltage: 208–230V
Phase: 1
Cycle: 60 Hz
Max Fuse Breaker: 30A
Min Circuit Ampacity: 29.5A

Refrigerant:
Refrigerant Type: R-454B
Refrigerant Volume: 105.82 oz

Sound Rating:
Decibel Rating: 60.5 dBA

Lineset Requirements:
Liquid Line Size: 3/8"
Suction Line Size: 3/4"

Smart Control:
WiFi Compatibility: Yes
App Compatibility: Yes

Certifications:
ETL Certified: Yes
Energy Star Certified: Yes
AHRI Certified: Yes

Warranty:
Parts Warranty: 10 Years
Compressor Warranty: 10 Years
Labor Warranty: 10 Years

Safety / Compliance:
Contains Electronics: Yes
Contains Chemicals: Yes
Contains Compressed Gas: Yes

Dimensions & Weight:
Net: 37.24" W × 31.89" H × 16.14" D
Gross: 42.91" W × 34.84" H × 19.68" D
